PH Crimped Wire 200mm (Wire Socket Crimp, Stripped & Tinned)

PH Crimped Wire 200mm (Wire Socket Crimp, Stripped & Tinned)

1 1
Wire Colour
Quantity Unit Price
1+ £0.13
5+ £0.117
10+ £0.104
20+ £0.091
50+ £0.078
100+ £0.0715

Part Specification

Part NumberPH-200-W200-RT-S3
Variant Colour:
White
Wire TerminationWire Socket Crimp / Stripped & Tinned
Wire Size26AWG
Wire Stranding7/0.12mm
Wire Outer Diameter1.3mm
Wire Length200mm
Part TypeCrimped Wire (Wire Socket)
Materials
  • Phosphor bronze
  • Tin
  • Copper
  • PVC

Series Specification

Series NamePH-200
Pin Pitch2.0mm
Maximum Voltage100V
Maximum Current2.0A
Temperature Range-25°C ~ 105°C
Contact Resistance10mΩ
Insulation Resistance1000MΩ
Withstand Voltage800V AC/min
Compatible Wire Size32AWG ~ 24AWG
Wire Insulation Size (OD)0.9mm ~ 1.5mm
Compatible PC Board Thickness1.6mm
Compatibility
  • JST PH
