SH Wire-to-Board Connectors

SH Wire-to-Board Connectors

1 1

Series Specification

Series Name SH-100
Pin Pitch 1.0mm
Maximum Voltage 50V
Maximum Current 1.0A
Temperature Range -25°C ~ 105°C
Contact Resistance 20mΩ
Insulation Resistance 100MΩ
Withstand Voltage 500V AC/min
Compatible Wire Size 32AWG ~ 28AWG
Wire Insulation Size (OD) 0.4mm ~ 0.8mm
Compatibility JST SH
