SMH250 Plug Housing 2-pin

Series: SMH250-SMP250-SMW250-250
Pin Count: 2-12
Pin Pitch: 2.5mm
Maximum Voltage: 250V
Maximum Current: 3.0A
Compatibility: Yeonho SMH250-NN / Yeonho SMP250-NN / Yeonho SMW250-NN

Name: SMH250 Plug Housing 2-pin
Brand: Komodo Electronics
SKU: SMH250-250-2Y
Price: 0.03 GBP
Availability: InStock

1 1

Product variants

Price

Quantity

Availability: 744 in stock

Part Information

Series Name	SMH250-SMP250-SMW250-250
Pin Pitch	2.5mm
Maximum Voltage	250V
Maximum Current	3.0A
Temperature Range	-25°C ~ 105°C
Contact Resistance	20mΩ
Insulation Resistance	1000MΩ
Withstand Voltage	1000V AC/min
Compatible Wire Size	28AWG ~ 22AWG
Wire Insulation Size (OD)	1.2mm ~ 1.9mm
Compatibility	Yeonho SMH250-NN Yeonho SMP250-NN Yeonho SMW250-NN
