TJC8 Wire-to-Board Connectors

TJC8 Wire-to-Board Connectors

Skip to product information
1 of 1

Series Specification

Series Name TJC8-254
Pin Pitch 2.54mm
Maximum Voltage 250V
Maximum Current 3.0A
Temperature Range -25°C ~ 105°C
Contact Resistance 20mΩ
Withstand Voltage 1500V AC/min
Compatible Wire Size 26AWG ~ 22AWG
Wire Insulation Size (OD) 1.2mm ~ 1.6mm
Compatibility
  • JST RE
  • HARWIN M20
  • Amphenol ICC Mini-PV
  • DuPont Standard Header

On This Page
