VH Wire-to-Board Connectors

VH Wire-to-Board Connectors

1 1

Series Specification

Series Name VH-396
Pin Pitch 3.96mm
Maximum Voltage 250V
Maximum Current 10.0A
Temperature Range -25°C ~ 105°C
Contact Resistance 10mΩ
Insulation Resistance 1000MΩ
Withstand Voltage 1500V AC/min
Compatible Wire Size 26AWG ~ 18AWG
Wire Insulation Size (OD) 1.7mm ~ 3.0mm
Compatibility JST VH
