SMP250 Wire Socket Crimp Terminal

Series: SMH250-SMP250-SMW250-250
Pin Count: 2-12
Pin Pitch: 2.5mm
Maximum Voltage: 250V
Maximum Current: 3.0A
Compatibility: Yeonho SMH250-NN / Yeonho SMP250-NN / Yeonho SMW250-NN

Name: SMP250 Wire Socket Crimp Terminal
Brand: Komodo Electronics
SKU: SMP250-250-RT
Price: 0.04 GBP
Availability: InStock

1 1

Product variants

Availability: 5272 in stock

Price

Quantity

Part Information

Part Number	SMP250-250-RT
Materials	Phosphor bronze Tin

Series Name	SMH250-SMP250-SMW250-250
Pin Pitch	2.5mm
Maximum Voltage	250V
Maximum Current	3.0A
Temperature Range	-25°C ~ 105°C
Contact Resistance	20mΩ
Insulation Resistance	1000MΩ
Withstand Voltage	1000V AC/min
Compatible Wire Size	28AWG ~ 22AWG
Wire Insulation Size (OD)	1.2mm ~ 1.9mm
Compatibility	Yeonho SMH250-NN Yeonho SMP250-NN Yeonho SMW250-NN
